1、features 60watts peak pulse power (tp = 8/20s) sot363 package solid-state silicon-avalanche technology low clamping voltage low leakage current low capacitance (cj=0.25pf typ.) protection one data/power line iec 61000-4-2 15kv contact 20kv airiec 61000-4-4 (eft) 40a (5/50ns)iec 61000-4-5 (lightning)
2、 3.5a (8/20s)applications ethernet digital visual interface (dvi) usb2.0 notebook and pc computersbst363a054uesd protection diode arraymechanical data sot363 package molding compound flammability rating: ul 94v-0 packaging: tape and reel rohs/weee compliant深圳市骊微电子科技有限公司半导体专业供应商schematic & pin config
3、urationi/o 16 i/ogndvcci/o 34 i/osot363 bst363a054uabsolute maximum ratingratingsymbolvalueunitspeak pulse power ( tp =8/20s)ppp60wattspeak pulse current ( tp =8/20s )(note1)ipp3.5aesd per iec 61000-4-2 (air)esd per iec 61000-4-2 (contact)vesd2015kvlead soldering temperaturetl260(10seconds)junction
4、temperaturetj-55 to 125storage temperaturetstg-55 to 125electrical characteristicsparametersymbolconditionsmintypicalmaxunitsreverse stand-off voltagevrwm5.0vreverse breakdown voltagevbrit=1ma6vreverse leakage currentirvrwm=5v,t=2550500napeak pulse currentipptp =8/20s3aclamping voltagevcipp=3.5a
5、,tp=8/20s1518vjunction capacitancecjvr = 0v, f = 1mhzio to io0.20.25pfvr = 0v, f = 1mhz io to gnd0.350.5electrical parameters (ta = 25c unless otherwise noted)symbolparameterippmaximum reverse peak pulse currentvcclamping voltage ippvrwmworking peak reverse voltageirmaximum reverse leakage current v
6、rwmvbrbreakdown voltage itittest current iippvc vbr vrwmitiriirvrwm vbr vctvippnote:. 8/20s pulsewaveform.typical characteristic curvesfig.1 peak pulse power rating curvefig.2 pulse derating curve160w 8/20s waveformpercent of rated power for ipp10110peak pulse power ppp(kw)00801600.140200.010.111010
